MC4 Female & Male connectors 2.5mm

LEADER® solar panel wire connectors CC4M is that new 1500V standard with UL and TUV approved, Compatible with 800+ solar module connectors, suitable for solar cable 2.5 mm², 4mm² and 6mm² in. Quickly and reliable connections of the solar cables to the photovoltaic system.

• Compatible with 800+ solar module connectors
• 15 Years of production experience in solar connectors
• 1500V TUV approved & Quick and easy to install
• Protection class IP68 Suitable for outdoor harsh environments
• Stable connection & Reducing maintenance cost

Data

1. Housing Material: PPO/PC
2. Contact material: Copper Tin-plated
3. Waterproof: IP68.
4. Rated Voltage: TUV 1500 VDC
5. Current: 30A
9. Pin Dimension: 4.0mm
13. For cable size: 2.5/4.0/6.0mm

What is in the box.

1 x MC4 Female Connector

1 x MC4 Male Connector
